外形及安装尺寸：
| 规 格 型 号 |
DZD10-0.4
|
DZD10-1
|
DZD10-2 |
DZD10-4
|
DZD10-8
|
DZD10-16
|
DZD10-25
|
| D1 |
80 |
100 |
125 |
150 |
190 |
230 |
280 |
| D2 |
72 |
90 |
112 |
137 |
175 |
215 |
260 |
| D3 |
35 |
42 |
52 |
62 |
80 |
100 |
120 |
| D4 |
46 |
60 |
76 |
95 |
120 |
158 |
185.5 |
| D5 |
63 |
80 |
100 |
125 |
160 |
200 |
241 |
| D6 |
26 |
31 |
41 |
49 |
65 |
83 |
100 |
| D |
15 |
15 |
20 |
25 |
30 |
45 |
55 |
| h |
17.3 |
17.3 |
22.8 |
28.3 |
33.3 |
48.8 |
59.3 |
| b |
5 |
5 |
6 |
8 |
8 |
14 |
16 |
| L |
22.5 |
24.5 |
28 |
31 |
35 |
41 |
48.5 |
| L1 |
37.5 |
44.5 |
53 |
61 |
73 |
83 |
98.5 |
| L2 |
25.5 |
28.5 |
33 |
37 |
42 |
50 |
60.5 |
| L3 |
15 |
20 |
25 |
30 |
38 |
42 |
50 |
| L4 |
12 |
16 |
20 |
24 |
31 |
33 |
38 |
| H |
3.5 |
4.3 |
5 |
5.5 |
6 |
7 |
8 |
| B |
1.7 |
1.7 |
2.2 |
2.2 |
2.7 |
2.7 |
3.2 |
| P |
6 |
8 |
10 |
12 |
15 |
16 |
18 |
| m |
2-M4 |
2-M5
|
2-M5
|
2-M6
|
2-M8
|
2-M8
|
2-M10 |
| V1 |
3-Φ6.3 |
3-Φ8
|
3-Φ10.5 |
3-Φ12 |
3-Φ15 |
3-Φ20
|
3-Φ20
|
| V2 |
3-Φ3.1
|
3-Φ4.1
|
3-Φ5.1
|
3-Φ6.1
|
3-Φ8.1
|
3-Φ10.2
|
3-Φ10.2
|
| V3 |
3-Φ6
|
3-Φ7.5
|
3-Φ9
|
3-Φ11
|
3-Φ14
|
3-Φ18.5
|
3-Φ18.5
|
| X |
1.5 |
2.8 |
3.8 |
5 |
6 |
8 |
8 |
| Y |
5 |
6 |
7 |
7 |
9.5 |
9.5 |
11 |
| δ |
0.2 |
0.2 |
0.3 |
0.3 |
0.3 |
0.5 |
0.5 |
|
